Transmitter

Receiver

Port

DC Input: 2.0mm Core Socket
HDMI Output: HDMI 1.4b
SDI Output: 3G SDI
USB-C: USB 2.0 OTG
Antenna: SMA Male

Power Supply

Battery Voltage Range: 6.8 – 8.4V
DC Voltage Range: 6 – 16V

Power Consumption

< 8W

Net Weight

207g

Dimensions

L × W × H: 112 × 71.2 × 34.1mm (4.4 × 2.8 × 1.3in.)

Input/Output Format

HDMI Output
720p50/59.94/60
1080i50/59.94/60
1080p23.98/24/25/29.97/30
1080p50/59.94/60
3840*2160 30/25/24/29.97/23.98
SDI Output?
1080p50/59.94/60
?1080i50/59.94/60
?1080p23.98/24/25/29.97/30
?720p50/59.94/60
?1080p23.98/24
1080i50/59.94/60

Operating Frequency

5 GHz Frequency Band
?5.150 – 5.250 GHz
?5.250 – 5.350 GHz
?5.470 – 5.725 GHz
?5.725 – 5.850 GHz
?2.4 GHz Frequency Band
?2.412 – 2.484 GHz

Transmit Power

/

Receiver Sensitivity

-85 dBm (Broadcast: -80 dBm)

Latency

as low as 50ms

Port

DC Input: 2.0mm Core Socket
HDMI Input: HDMI 1.4b
SDI Input: 3G SDI
USB-C: USB 2.0 OTG
Antenna: SMA Male

Bandwidth

20 MHz
(Broadcast: 40 MHz)

Temperature

-10 – 45? (working)
-40 – 60? (storage)
